Heat Recovery decentralized Ventilation Unit BOUL EVOLUTION BOUL RECUPERATORS

Heat Recovery decentralized Ventilation Unit BOUL EVOLUTION

Single Room VENTILATION. Remote control.
HRV System KIT

About this item

Ventilation with heat recovery. Recuperator supplies clean and fresh air all year round. The supply and exhaust ventilation system is suitable for housing (private houses, cottages, apartments), offices, workshops, small shops, boutiques, cafes, restaurants, hairdressers, classrooms, health and education institutions, kindergartens, schools, etc. It is especially important after repairs in the room after the installation of windows that seal it (!)
Intra-wall mounted ventilation unit. Controlled mechanical ventilation with high-efficiency heat recovery/recuperation up to 94%.
Aluminum heat storage (exchanger) transfers heat very efficiently.
The supply and exhaust channels exist separately, so the air flows do not mix (!). Operating modes - 4. Recuperation at 100 m³/_h each. Remote Сontrol. Serviced room area up to 40 m².
The device is equipped with air valves.
The inclination of the device towards the street is built into the heat exchanger constructively. So when drilling a hole in the wall, there is no need to do it at an angle.

Product description

Designed for comfortable ventilation of rooms with a small number of people (up to 5).
The recuperator provides clean and fresh air all year round without the need to open windows. Internal wall mounting. Controlled mechanical ventilation with energy efficient body exchanger. Aluminum heat exchanger has a high efficiency.
BOUL EVOLUTION system has 4 operating modes: recuperation, supply, exhaust +smoth speed setting for each fan. In the first case the device works as a supply and exhaust ventilation system (supply and exhaust fans are switched on simultaneously), in the second and third cases the system activates only the air supply from the street (only the supply fan is on) or only the exhaust (only the exhaust fan is on).
To define the heat exchanger operating modes, one or two LEDs are switched on, indicating the selected mode.
The exhaust channel has an automatical (petal) valve, the supply one has a mechanical valve with manual adjustment. When viewed from the user's side, turning the wheel clockwise means the valve is CLOSED, when turning counterclockwise means the valve is OPEN. This is described in more detail in the technical data sheet of the product.

Technical characteristics

Heat recovery efficiency (recuperation efficiency) up to 94%
Operating mode: 4. Recuperation (synchronized supply and extract), supply, extract, + smoth speed setting for each fan.
Recuperation mode: ¹⁰⁰/₁₀₀ m³/_hour
Recuperator length (in the wall): 440 mm. It can be increased at the request of the customer (440-500 mm)
Total length: 620 mm. Diameter: 175 mm. Mounting hole diameter not less 180 mm.
Power consumption: 10-30 ^W/_hour
Supply voltage: 110-240V
Noise level, dB: 28-36
Control: Remote control, smooth speed control on the body.
The set includes a wire connecting the device 0.2 m
Weight: 4 kg
Set includes: Recuperator, Remote control, technical documentation (Eng). Original box
